ONE RING
ONE RING is a decorative yet highly technical fixture with a minimal design and multiple application possibilities. Available in a range of diameters, for direct ceiling or suspended mounting, with direct or direct/indirect light emission and the possibility of adding adjustable spotlights for accent lighting. With the option of including a central acoustic with sound absorption panels, ONE RING is a truly unique lighting solution.
Technical features
Optics
Body
Certifications
On request
- 3000K/4000K
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L90/B50 >50.000h
- IP 40
- Direct emission
- Direct/indirect emission
- Satin methacrylate diffuser for homogeneous emission UGR<22
- Impact resistant DPL diffuser with homogeneous and controlled emission, UGR<19
Aluminum with epoxy powder coating
- CE Conformity
- RETILAP Conformity
- ETL Conformity
- Energy efficiency C
- 5 years warranty
- 0-10V
- 3500K
Technical features
- 3000K/4000K
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L90/B50 >50.000h
- IP 40
Optics
- Direct emission
- Direct/indirect emission
- Satin methacrylate diffuser for homogeneous emission UGR<22
- Impact resistant DPL diffuser with homogeneous and controlled emission, UGR<19
Body
Aluminum with epoxy powder coating
Certifications
- CE Conformity
- RETILAP Conformity
- ETL Conformity
- Energy efficiency C
- 5 years warranty
On request
- 0-10V
- 3500K
ONE RING
versions
PRODUCT CODE
PRODUCT CODE example
size
A
FAMILY
ECONR ONE RING
B
POWER
ST – Standard power
DP – Decrease power (only for DP, DP followed by up two numbers for indicate the power)
C
LIGHT DISTRIBUTION
DR – Direct emission
DE – Double emission
D
OPTICS
PG – Methacrylate satin diffuser
DP – Diamond prism technology
E
MOUNTING
P1 – Pendant 59.05”(with flexible cord and power box)
P3 – Pendant 118.11” (with flexible cord and power box)
SM – Surface mount (ceiling)
F
FINISH COLOR
WH – White
BK – Black
G
DIAMETER
031 – 31.1”
045 – 44.9”
060 – 59.5”
H
LED CCT
309 – 3000K CRI90
359 – 3500K CRI90 (on request)
409 – 4000K CRI90
I
WIRING
2S – 0-10V Dim
3S – ON/OFF
LUMEN PACKAGE
4000K
ONE RING PG
31.1"
LP
DR
39W 4173lm
DE
63W 6057lm
44.9"
LP
DR
58W 6216lm
DE
93W 8966lm
59.5"
LP
DR
77W 8288lm
DE
123W 11588lm
ONE RING DP
31.1"
LP
DR
39W 3950lm
DE
63W 5834lm
44.9"
LP
DR
58W 5880lm
DE
93W 8630lm
59.5"
LP
DR
77W 7840lm
DE
123W 11140lm
